Name: 3M AF42
Brand: 3M Netherlands B.V.
SKU: 3M AF42

Main features

Clear Structural Bondline
Clean Non Tack Layup
High Peel Toughened Film

Product Description

3M Thermal Bonding Film AF42 is a translucent, non-tacky epoxy thermoset film for structural attachment of metal, glass, and engineering-grade substrates in electronics assemblies. The 3 mil adhesive layer is supplied on a 6.5 mil brown paper liner for clean cutting and placement. Low flow supports bondline control during heat cure, and the adhesive cures clear. A 60 minute cure at 177 deg C develops the final bond, while alternate higher-temperature cycles support shorter processing times.

Key features

Clear Cured Bondline: The translucent film cures to a clear structural adhesive layer.
Non Tack Low Flow Handling: The preformed film supports clean placement and controlled flow during cure.
Heat Cured Structural Bonding: The epoxy film bonds compatible metals, glass, and engineering substrates.

Applications

Electronics assembly bonding, metal and glass attachment, and structural film bonding with a compatible heat-cure process.

TDS, SDS & Technical Documents

Technical Specifications

General Properties

Color

Translucent

Mechanical Properties

Elongation

350 %

Additional Information

Technical properties

As-supplied / before-processing properties

Property	Value	Unit	Method / condition
Base resin	Epoxy	-	As supplied
Adhesive thickness	3	mil	Nominal
Liner thickness	6.5	mil	Brown paper liner
Tack	None	-	At room temperature
Color	Translucent	-	Before cure
Room-temperature work life	4	weeks	At 21 deg C
Shelf life	15	months	Stored at 4 deg C
